9
Chapter 2: Prerequisites
Product Service Domestic 1-800-522-7658, International 816-333-8811
Space Requirements
Refer to Appendix C: RapidVap Specifications for
dimensional drawings of the RapidVap.
Tools Required
Common hand tools are required to set up the
RapidVap. A screwdriver or 5/16" socket is needed to
attach hose clamps. A tubing cutter or knife is needed
to shorten exhaust hoses. If the sample block must be
installed or exchanged, attaching nuts on the RapidVap
Vacuum and RapidVap N
2
require a 7/16" socket. The
manifold guides, which secure the block on the
RapidVap N
2
/48, require a 9/16" socket.
Your Next Step
After you have determined that the location for your
RapidVap accommodates the installation and
operational requirements, you are ready to unpack and
install your RapidVap. Proceed to Chapter 3: Getting
Started.
