Getting Started

BV10-100 and BV10-1000

13

Connecting the Power

The following figures show the –48 V and +24 V DC units.

-

-

2. Connect the plug to one of the two DC input connectors on the BV10

unit and tighten the screws firmly.

48 V DC Unit

Supplied connector

Negative (

) supply wire lead on the left

Positive (+) supply wire lead on the right

+24 V DC Unit

Supplied connector

Negative (

) supply wire lead on the left

Positive (+) supply wire lead on the right
