Working with iOLM files
212 FastReporter 2
Understanding the Link View

Pass/Fail not tested: A gray background indicates that the element is
unknown. If there is no icon at the right side corner, it indicates that
thresholds are not applied on the element and the element is not
tested for Pass/Fail. If you are viewing multiple measurements in Cable
view (see Managing Multiple Measurements on page 213 for details),
the status depends on the statuses of the corresponding matched
elements. If at least one of the elements has a status of fail, then the
combined element status is also fail. If the statuses are a combination
of pass and unknown, then the cable combined element status is set to
unknown.

Diagnostics icon: This icon specifies that some diagnostic is present
on the element. See Understanding Diagnostics on page 254 for more
details.

Distance Unit: The distance unit you have selected.

Splitter Ratio: The splitter ratio is displayed on the element, if the
element type is splitter.
Note: The number of elements displayed in the composition view varies
according to the available space, number of elements, and section size.
Note: When the link length is large, not all of the elements are visible; you may
need to scroll on the link using the navigation arrow.
Note: The distance between the elements is not 100 % proportional. To have a
proportional representation of the element, look at the link overview.
