Modifying space between traces on the graph – EXFO FastReporter 2 User Manual
Page 180
Working with OTDR Files
170
FastReporter 2
Modifying Space Between Traces on the Graph
Modifying Space Between Traces on the Graph
For easier viewing of the traces appearing on the graph, you can increase
or decrease the vertical space between each of them.
To increase or decrease the space between the traces:
1. On the toolbar, select the
button.
2. Use the buttons in the toolbar or menu to increase or decrease the
space between the traces.
An indicator on the left of the graph shows that an offset is applied.
If you are using a keyboard and mouse, you can press and hold the Shift
key to select the trace, then use the arrow buttons, or the mouse to drag it
to the desired location.
Reset spacing
Decrease spacing
Increase spacing
Activate Y spacing
