Fiber Inspection Probe
85
B Fiber Inspection Probe Tip
Compatibility Chart
With some tips that include lenses, and before performing an automatic
focus, you must adjust the focus manually for the first inspection.
Note: The tips for which the probe requires a manual focus before the first
inspection are listed in the table below.
To reach the focus level manually:
1. Bring the focus manually close to the focal point.
2. Activate the auto focus or press the magnification control button on the
probe and hold it down until the auto focus is activated again.
The table below establishes the Fiber Inspection Probe tip compatibility
with the different operations: fiber inspection, auto analysis (option), auto
focus (option), and auto detection (option) provided with the
ConnectorMax2 Mobile application:
Tip Description
Tip Code
Inspection
(all models)
Analysis
(FIP-425B
and
FIP-435B)
Auto focus
(FIP-435B)
Connector
Auto
detection
(FIP-435B)
Uni.2.5mm for PC
connector
FIPT-400-U25M
OK
OK
OK
OK
Uni.2.5mm for APC
connector
FIPT-400-U25MA
OK
OK
OK
OK
Uni.1.25mm for PC
Connector
FIPT-400-U12M
OK
OK
OK
OK
Uni.1.25mm for
APC connector
FIPT-400-U12MA
OK
OK
OK
OK
FC APC tip for
bulkhead adapter
FIPT-400-FC-APC
OK
OK
OK
OK
FC and SC tip for
bulkhead adapter
FIPT-400-FC-SC
OK
OK
OK
OK
