Setting up Your Fiber Inspection Probe and ConnectorMax2 Mobile
Fiber Inspection Probe
29
Setting Up Auto Capture
Setting Up Auto Capture
Note: The auto capture is a feature available for FIP-435B probes only.
As soon as the application detects that you are working in Live Video
mode, the feature is enabled in the Application Settings, and if the focus
level is acceptable, a capture is made automatically. This is known as the
auto capture.
Note: The auto capture is possible only in high magnification.
To enable the auto capture:
1. From the main window, tap
.
Note: Depending on the smart device you are using, the application settings can
be found in the menu button instead.
