EXFO FIP-425B/435B Fiber Inspection Probe and ConnectorMax2 Mobile User Manual
Page 75

Maintenance
Fiber Inspection Probe
67
Recharging the Battery
The micro USB adapter connector recharges the battery of the probe when
it is low. You can recharge the battery with the provided USB cable and the
adapter/charger that you connect to a power outlet. You can also use the
provided USB cable alone that you connect to a USB port of a computer.
When the probe is connected to a power outlet or to a USB port, it still
works via Wi-Fi.
When the probe is connected to the USB port of a computer (500 mA),
here are the possible cases for the charging process:
Status
FIP-425B
FIP-435B
Live Video mode
Charging
Not charging
Capture/Archive
Charging Charging
OFF
Charging
Charging
