Managing files – EXFO FIP-425B/435B Fiber Inspection Probe and ConnectorMax2 Mobile User Manual
Page 60

Inspecting Fiber Ends
52
FIP-400B
Managing Files
Managing Files
You can open captured files directly from the smart device to view them.
All saved measurements are available in Archive mode. The application
scans the smart device periodically and store the .cmax2 files here:
Storage/Emulated/0/Documents/EXFO/cmax2. For smart devices
supporting Android 4.4 (kit kat) and above, the files are sent to the
following folder: /Android/data/com.exfo.cmax2.mobile.android/files/.
You can also delete unwanted files. By default, all files are highlighted but
you can unselect the files you want to keep by pressing and holding the
screen. Otherwise, all files will be deleted.
To share files, see Transferring Results With Third-Party Applications on
page 60.
The .cmax2 files, when saved with the ConnectorMax 2 smart device, are
compatible with any EXFO applications.
To open a file:
1. From the main window, tap
.
