Maintenance

70

FIP-400B

Replacing the Battery

5. Remove the battery.

6. Replace the battery, respecting the polarity (black, yellow, and red

wires).

7. Close the battery compartment door.

8. Using a screwdriver, put the screws that you have removed at step 3

back in place.

Battery

Wires
