Introducing the FIP-400B Fiber Inspection Probe and ConnectorMax2 Mobile

Fiber Inspection Probe

3

Available Models

Available Models

The features available for your probe are automatically detected when you
connect it to your smart device. The table below shows which feature is
available for each model.

Note: When the internal temperature of the FIP-435B is too low, the probe

performs a warm-up that can last up to a minute.

Probe Tips

The FIP-400B comes with two interchangeable tips included in two
different packages (UPC or APC). Additional models are also available.

UPC package:

FIPT-400-FC-SC: FC-SC Bulkhead tip

FIPT-400-U25M: Universal patchcord tip (2.5 mm ferrule)

APC package:

FIPT-400-SC-APC: SC APC tip for bulkhead adapter

FIPT-400-U25MA: Universal patchcord tip for 2.5 mm ferrules

Other tip models are available for various bulkhead adapters and
patchcord connectors. For more information about tips and their use, see
the Fiber Inspection Probe Tip Compatibility Chart on page 85, or visit the
EXFO Web site.

Models

Inspection

Auto analysis Auto centering Auto focus Auto capture

FIP-425B

X

X

X

-

-

FIP-435B

X

X

X

X

X
