EXFO FIP-425B/435B Fiber Inspection Probe and ConnectorMax2 Mobile User Manual
Page 36

Setting up Your Fiber Inspection Probe and ConnectorMax2 Mobile
28
FIP-400B
Setting up the Increment
2. If necessary, select the Increment tab.
3. Move the increments from the Inactive Increments to the Active
Increments space by tapping . You can remove the identifiers by
tapping . You can also move the identifiers with the drag and drop
gesture.
Note: Only the identifiers with values are displayed.
4. When an increment is moved to the Active Increments, enter the start,
stop and increment values as desired.
Note: To decrement values, the start number must be higher than the stop
number.
5. Tap to confirm your new settings and to return to the main window.
The new settings will apply the next time you perform a capture.
