Setting up Your Fiber Inspection Probe and ConnectorMax2 Mobile
Fiber Inspection Probe 25
Setting up the Increment
Setting up the Increment
The file name is made of one or more static parts (alphanumeric) and one
or more variable parts (numeric) that will be incremented or
decremented, according to your selection, as follows:
Note: To decrement values, the start number must be higher than the stop
number.
The file name can be incremented using one or more identifiers. Selecting
a single identifier will follow the incrementation (or decrementation) value
you have set.
When selecting more than one identifier, the latter appear sequentially in
the order that you have set, and the incrementation will start with the last
item in the list (the one with the farthest indentation). For example, if you
have a file name with the Location, Cable and Fiber identifiers, in that
order, the first item to be incremented is the Fiber identifier, then Cable,
then Location:
Location 1, Cable 1, Fiber 1
Location 1, Cable 1, Fiber 2
Location 1, Cable 2, Fiber 1
Location 1, Cable 2, Fiber 2
and so forth.
If you choose incrementation... If you choose decrementation...
Variable part increases until it
reaches the highest possible value
with the selected number of digits,
then restarts at 1.
Variable part decreases until it
reaches 1, then restarts at the highest
possible value with the selected
number of digits.
