Fiber Inspection Probe

83

A Technical Specifications

I

MPORTANT

The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com
.

PRELIMINARY SPECIFICATIONS

a

Size (H x W x D)

55 mm x 39 mm x 207 mm (2

3

/

16

in x 1

1

/

2

in x 8

1

/

8

in)

b

Weight

0.3 kg (0.7 lb)

Resolution

0.55 μm

Camera sensor

Five-megapixel CMOS

Visual detection capability

<1 μm

Field of view

304 μm x 304 μm (high magnification)
608 μm x 608 μm (mid magnification)
912 μm x 912 μm (low magnification)

Light source

Blue LED

Lighting technique

Coaxial

Capture button

Available on all models

Magnification button

Available on all models

Digital magnification

Three levels

Connector

Micro USB

Connectivity

Wi-Fi 802.11

Frequency band

2.4 GHz

Smart device OS compatibility

c

Android™ 4.2 and above

Power

1 x removable battery

Autonomy

d

FIP-425B:

*8 hours

FIP-435B:

*6 hours

Recharge time

e

)4 h

Distance range

f

2.5 m (8.2 ft)

Notes

a. Typical.

b. Measurement excluding tip.

c. Software qualified with Samsung Galaxy™ device. Other Android models are not guaranteed to be 100% compatible.

d. One (1) test per minute. The probe remains in live mode for 20 seconds during each test.

e. When probe is in use the recharge time may take longer.

f. Wi-Fi interferences and physical obstacles may affect distance range.
