OTDR 1
1 Introducing the AXS-100
Series OTDR
The AXS-100 Series OTDR is a compact handheld OTDR optimized for
access/FTTx network testing. The unit can be equipped with optional
power meter, visual fault locator (VFL), and fiber inspection probe.
Main Features
³
Test can be started by pressing a single key
³
Possible to test with acquisition duration as short as 5 seconds
³
One or two OTDR ports (singlemode, multimode, or singlemode live)
³
Screen optimized for outdoor use
³
USB ports (host and client)
³
FTTx software package (optional): macrobend, fault finder, and
pass/fail indicators
³
Network testing (ping and trace route)
AC adapter/charger connector
Battery charge
status LEDs (one per battery)
RJ-45 connector
Shoulder strap eyelet
Stand
Display
Keypad
