Measuring Power or Loss

80

AXS-100 Series

Defining the List of Favorite Wavelengths

Defining the List of Favorite Wavelengths

You can put the wavelengths you want to use on a list of favorite
wavelengths. Only wavelengths selected from this list are available for
measurements.

By default, the list contains all the calibrated wavelengths: 850 nm,
1300 nm, 1310 nm, 1490 nm, 1550 nm, 1625 nm, 1650 nm.

Note: The list must always contain at least one selected wavelength.

To customize the list of favorite and selected wavelengths:
1.
Press Menu, select Setup > Power Meter, and then press Enter.

OR

From the Power Meter pane, press Setup (F1/F2 key).

2. Using the up/down arrows, scroll through the

list.

3. Press Enter to select/deselect the highlighted

wavelength.

OR

Press Select (F1 key).

A check mark appears beside selected wavelengths.

4. Repeat these steps for other wavelengths as necessary.
