Managing Test Results
54 AXS-100 Series
Events Pane
Events Pane
This pane shows the list of events found during the test.
You can select Events (F1/F2 keys) to display the pane. Values appearing in
white on a red background exceed the defined thresholds.
Wavelength of the displayed trace
Use left/right arrows to switch
between the different
wavelengths
You can select an item
with up/down arrows
and press Enter to
switch to Trace pane.
Event type (see Description of
Event Types on page 127 )
