Page 43
Quick Start Guide
LCD Panel Open - Model D 1 - 11
1
LCD Panel Open - Model D
Figure 1 - 6
LCD Panel Open
Model D
1. Built-In 2.0M HD
PC Camera
2. PC Camera LED
3. Built-In Array
Microphone
4. LCD
5. Speakers
6. Power Button
7. LED Status
Indicators
8. Illuminated
Keyboard
9. Touchpad and
Buttons
10. Fingerprint Reader
Module
4
1
9
7
8
5
6
2
3
3
5
10
Note that the Touchpad and
Buttons has a valid operational
area indicated within the dotted
lines above. See
