Quick Start Guide
1 - 8 LCD Panel Open - Model B
1
LCD Panel Open - Model B
Figure 1 - 3
LCD Panel Open
Model B
1. Built-In 1.0M HD
PC Camera
2. PC Camera LED
3. Built-In Array
Microphone
4. LCD
5. Volume Bar LED
6. Speakers
7. Power Button LED
8. LED Status
Indicators
9. Illuminated
Keyboard
10. Illuminated/Non-
Illuminated
Touchpad
11. Touchpad Buttons
12. Fingerprint Reader
Module
Note that the Volume Bar LED
will not oscillate if the volume
level is set lower than 20%
4
1
10
8
9
6
7
2
3
5
3
6
11
12
Note that the Illuminated/
Non-Illuminated Touchpad
has a defined valid operation-
al area of sensitivity indicated
within the sensor area of the
illustration below. See
“Clickpad/Touchpad Sensi-
tivity (Models A, C & D)” on
page 2 - 12
.
