1 - 10 LCD Panel Open - Model C

Quick Start Guide

1

LCD Panel Open -

Model C

Figure 1 - 5

LCD Panel Open

Model C

1. Built-In PC Camera
2. PC Camera LED
3. Built-In

Microphone

4. LCD
5. Speakers
6. 3D Emitter
7. LED Status

Indicators

8. Power Button
9. Illuminated

Keyboard

10. Clickpad and

Buttons

11. Fingerprint Reader

Module

4

1

11

9

7

8

2

3

5

5

6

10

Note that the Clickpad and But-
tons has a valid operational area
indicated within the dotted lines
above. See

“Clickpad/Touch-

pad Sensitivity (Models A, C &
D)” on page 2 - 12

.
