Upgrading The Computer
6 - 12 Upgrading the Hard Disk Drive(s)
6
Inserting the Hard Disk into the Upper HDD Bay Slot
1. Insert the HDD assembly into the bay at the angle indicated by arrow .
2. Place the HDD assembly flat into the bay as indicated by arrow .
3. Slide the assembly firmly into the connector (the reverse direction to the arrow in
Figure 6 - 6 on page 6 - 10 ).
Figure 6 - 8
HDD Assembly
Insertion
1
2
1
2
