Eurocom X7 User Manual
Page 173
Upgrading The Computer
Upgrading the Hard Disk Drive(s) 6 - 11
6
8.
Remove screws
-
and separate the hard disk from the insulation plate
.
9.
Reverse the process to install any new disk (and do not forget to install the
insulation plate and screws (see over for cover).
9
12
Figure 6 - 7
Upper Bay Hard
Disk Insulation Plate
Removal
13
9
10
11
12
13
