Fasten the knob to the shaft of the
capacitor with a screw.
Rotate the knob fully clockwise.
Peel off the protective backing on
the label. Line up the long white
lines on the label with the arrows
on the PC board.
ASSEMBLY INSTRUCTIONS
PC Board Stand
Insert the PC board into the stand as shown.
Screw
M2.5 x 7.5mm
Knob
Figure P
Figure O
