52
Table 17 - Carlin (CHIMNEY VENT) Preliminary Burner Settings
Burner settings provided are for initial startup only. Final adjustments must be made using combustion test
instruments.
17 - OIL BURNER, NOZZLE, & AIR SETTINGS
TABLE 1 - CARLIN SETTINGS
BOILER
NO.
INSER-
TION
DEPTH
FIRING
RATE
COMBUS-
TION
LINER
NOZZLE
MFR.
NOZZLE
TYPE
PUMP
PRESSURE
[PSI]
HEAD
BAR
AIR
BAND
SETTING
Rated
AFUE
Efficiency
[%]
4075 3.00” 0.75 OVAL DANFOSS 0.60 x 60 AS 160 0.60/0.65 25% 86.0
4095 3.00” 0.95 OVAL DELAVAN 0.75 x 45 W 160 0.75 35% 85.0
4110 3.00” 1.10 OVAL DELAVAN 0.85 x 60 A 165 0.75 50% 84.0
5100 3.00” 1.00 NONE HAGO 0.75 x 60 B 175 0.75 35% 86.5
5115 3.00” 1.15 NONE DELAVAN 0.85 x 45 A 180 0.85/1.00 40% 85.0
5135 3.00” 1.35 NONE DANFOSS 1.10 x 60 AB 150 1.10/1.25 45% 84.0
TIMINGS
Pre-Purge
15 seconds
Post Purge 15 seconds
Boiler
Model
Carline
Burner
Model
ECR Oil
Burner Part
Number
4075 EZ-LF 240010357
4095 EZ-LF 240010357
4110 EZ-LF 240010357
5100 EZ-LF 240010357
5115 EZ-LF 240010357
5135 EZ-LF 240010357
