98
DCS-6620G User’s Manual
D-Link Systems, Inc.
Using IP surveillance Software
Monitor Program (continued)
Alert Message
If you have checked the box for “Enable Motion Detect” or “Enable Digital Input” on “Camera
Configurations > Alert Settings“ screen, the alert message will show in the window shown
above. Once the alert, caused by motion detection or a digital input level changer, is triggered,
the alert message will be shown in this window. If there are more events than this window can
display, a scroll bar will appear.
The message format is described as follows:
“time”=>”alert type” #”channel number”(“win1”,”win2”,”win3”)
For example, the message “PM 02:41:00=>MO #1(0,1,1)” means that this is a motion detection
alert occurring at 02:41:00 PM in Motion Window 2 and Motion Window 3, for camera #1. If
the message “PM 02:41:56=>DI #1” is listed, that means there is an alert triggered by the DI,
for camera #1, at 02:41:56 PM .
