51
DCS-6620G User’s Manual
D-Link Systems, Inc.
Using the DCS-6620G with an Internet Browser
You may press to fine-tune the image and see what effect the setting will have on the
image. When the image is acceptable, press to store the image settings, or to
recall the original settings. If settings are changed without saving, they will be used until the
next system start-up.
Configuration > Advanced > Image Setting (continued)
Click the video button from the Configuration screen to access video settings that affect
how the video image appears.
Image Brightness, Contrast, Saturation and Hue are all adjusted in the same manner. For each
video compensation you can set from among eleven levels ranged from -5 to +5.
From this screen you can fine tune the video image.
Configuration > Advanced > CCD Setting
Click CCD Setting
Auto electronic shutter:
Low lux mode:
Once the shutter is selected as “Auto”, the IRIS of the
CCD will become fixed. Select this setting if you select
Low lux mode.
Checking this box will assist in seeing objects in poor
illuminative environments.
Apply when the
DCS-6620G is aiming outdoors. Adjusting
the 9 levels of white levels can help the camera to capture
video with correct colors.
Auto tracking white balance:
