107
DCS-6620G User’s Manual
D-Link Systems, Inc.
Using IP surveillance Software
Scheduling (continued)
Apply and Erase Buttons
After you have selected the time period with “Begin time” and “End time” picker, you can apply
the period picker, shown in the figure below, to set the periodical types of the time interval set
previously. After the settings in “Begin Time”, “End Time” and “Period Picker” are all done, you
should click the “Apply” button or “Erase” button to add or clear this scheduling information to
the editing schedule scheme. Note that only after you click on the “Apply” button, the scheduling
information settings will be written back into the whole editing schedule scheme. That means
this edited scheduling time interval is valid only after you “Apply” the changes.
Period picker Apply Erase
Schedule in event mode
You can select to record in Event mode or Continuous mode by the Schedule mode selector as
shown in the figure below. There are two types of event recording. Please refer to the following
two sections for more information.
Motion Detection
As shown above, you can check the windows to determine which window(s) will be used to
trigger the recording. The motion windows are labeled in the order in which they are added
when configuring motion detection for the camera. For example, Window1 is the first window
added, regardless of if the name of the window has been changed.
