Connections
Located on the bottom panel of the
DCS-6620G, the socket is used to connect the camera stand
to the 802.11g PTZ Internet Camera by attaching the screw head on the camera stand to the
802.11g PTZ Internet Camera.
Bottom Panel
Attachment socket for the Camera Stand
The
DCS-6620G provides a terminal block with two pairs of connectors situated on the back
panel. One pair is for input and the other is for output. The External I/O Port provides the
physical interface to send, and receive, digital signals to a variety of external alarm devices.
Please refer to the appendix in this manual for detailed information (page 133).
External I/O Port
Socket for stand
