External I/O Port
Configuring Your Camera for External Trigger Based Recording (continued)
Next, click the Applications button under
the Tools tab to set the application
settings for the DCS-6620G.
In this window, follow the steps below to set the application settings for snapshots to be sent
to your e-mail account or FTP server when triggered by a motion sensor or other external
device:
 Select the weekdays you would like to record and enter the “Snapshots begin” time
and “Snapshots end” time for the weekly schedule, or select “All the time except for
the above schedule” if you want to enable full time snapshot recording.
 Check “Event operation.”
 Set the delay “before detecting next event” to avoid continuous false alarms
following the original event.
 Set the delay to “take snapshots after event” to capture the direction of the moving
object.
 Check the trigger condition for input and motion detection (in this case “Input is
Low”).
 Check “Trigger output alarm while input condition matched” and “Upload
snapshots while motion detected.”
 Select to either send snapshots by e-mail or by FTP.
Click Applications
Click the apply button when finished. You are now able to send snapshots, based on triggered
recording, to your e-mail account or FTP server.
