Speaker system SX-NA502
Main unit CX-NA508
FM tuner section
Tuning range
Usable sensivity (IMF)
Antenna terminals
AM tuner section
Tuning range
Usable sensitivity
Antenna
Amplifier section
Power output
Total harmonic distortion
Inputs
Outputs
Cassette deck section
Track format
Frequency response
Recording system
Heads
87.5 MHz to 108 MHz
13.2 dBf
75 ohms (unbalanced)
530 kHz to 1710 kHz (10 kHz step)
531 kHz to 1602 kHz (9 kHz step)
350 pV/m
Loop antenna
60 W + 60 W (50 Hz - 20 kHz, THD
less than 1%, 6 ohms)
0.05 % (50 W, 1 kHz, 6 ohms, DIN
AUDIO)
VIDEO/AUX: 150 mV (adjustable)
MD: 150 mV (adjustable)
MIC: 1.8 mV (10 k ohms)
LINE OUT: 200 mV
SUPER WOOFERS: 1.9V
SPEAKERS: accept speakers of 6
ohms or more
SURROUND SPEAKERS:
accept speakers of 8 ohms fo 16
ohms
PHONES (stereo jack): accepts
headphones of 32 ohms or more
4 tracks, 2 channels stereo
50 Hz - 15000 Hz
AC bias
Deck 1: Playback head x 1
Deck 2:Recording/playback head
X 1, erase head x 1
Compact disc player section
Laser
D-A converter
Signal-to-noise ratio
Harmonic distortion
Wow and flutter
General
Power requirements
Power consumption
Dimensions of main unit
(W X H X D)
Weight of main unit
Semiconductor laser {X = 780 nm)
1 bit duai
85 dB (1 kHz, 0 dB)
0.05 % (1 kHz, 0 dB)
Unmeasurable
120 V AC, 60 Hz
100 W
260x329.1 X 344.5 mm
(10'/4 X 13 X 13V b in.)
6.4 kg (14 lbs 2 oz.)
Cabinet type
Speakers
Impedance
Output sound pressure level
Dimensions (W x H x D)
Weight
3 way, bass reflex (magnetic
shielded type)
Woofer:
140 mm (5 Vs in.) cone type
Tweeter:
60 mm (2 Vs in.) cone type
Super tweeter:
10 mm ('%2 in.) ceramic type
6 ohms
87 dB/W/m
235 X 324 x 250 mm
(9 Vs X 12 Vs X 9 Vs in.)
3.3 kg (7 lbs 4 oz.)
Specifications and external appearance are subject to change without
notice.
mu
SYSTEM
The word “BBE” and the “BBE symbol” are trademarks of BBE
Sound, Inc.
Under license from BBE Sound, Inc.
COPYRIGHT
Please check the laws on copyright relating to recordings from
discs, radio or externai tape for the country in which the machine
is being used.
NOTE
This equipment has been tested and found to comply with the
limits for a Ciass B digitai device, pursuant to Part 15 of the FCC
Rules.These limits are designed to provide reasonabie protection
against harmfui interference in a residentiai instaliation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not instailed and used in accordance with the
instructions,
may cause harmful interference to radio
communications. However, there is no guarantee that
interference wiil not occur in a particuiar instaiiation. if this
equipment does cause harmfui interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference
by one or more of the foiiowing measures:
- Reorient or reiocate the receiving antenna.
- increase the separation between the equipment and receiver.
- Connect the equipment into an outiet on circuit different from
that to which the receiver is connected.
- Consuit the deaier or an experienced radio/TV technician
for heip.
CAUTION
Modifications or adjustments to this product, which are not
expressiy approved by the manufacturer, may void the user’s
right or authority to operate this product.
<
K
III
z
111
o
ENGLISH 22
