Aiwa NSX-A508 - Manual (Page 17)

KARAOKE
KARAOKE
VOCAL FADER/MULTIPLEX FUNCTIONS
This unit can use discs or tapes as Karaoke sources.
Use the vocal fader function for ordinary discs or tapes.
Use the multiplex function for multi audio discs or tapes.
Press KARAOKE repeatedly to select the vocal fader or
multiplex function.
Each time KARAOKE is pressed, one of these functions is
selected cyclically.
© @ @
,r -©i i
; —^ H........ UF - -5. ivpx................i...
1
© ■A
i * * /
UF OFF -s- M................ i■1px <■ .
A microphone (not supplied) can be connected to this unit,
allowing you to sing along to music sources.
Use a microphone with mini plugs (03.5 mm. Vs inch).
1 Connect your microphone to the MIC jack.
MIC 1
2 Press one of function to seiect the source to be
mixed, and play the source.
3 Adjust the volume and tone of the source.
4 Turn the MIC VOLUME control to adjust the
microphone volume.
To record microphone sound mixed with source sound
Follow the procedure for recording from the sound source (see
page 12).
SYNCHRO DUBBING cannot be used for mixing recording.
When not using the microphone
Set the microphone volume to MIN and remove the microphone
from the MIC jack.
• If a microphone is held too near the speakers, a howling sound
may be produced. In this case, hold the microphone away
from the speakers, or decrease the microphone volume.
• If sound through the microphone is extremely loud, it may be
distorted, in this case, decrease the microphone volume.
Recommended microphone
The use of unidirectional type microphone is recommended to
prevent howling. Contact your local Aiwa dealer for details.
• The Karaoke functions may not operate correctly with the
following kinds of CDs or tapes.
- Those with monaural sound
- Those recorded with strong echoes
- Those with the vocal part recorded on the right or left side of
the sound width
•While the Karaoke function is on, the sound is output as
monaural.
• When the function is changed, the Karaoke function is canceled.
(9
Z
5
oc
o
o
u
oc
Ul
z
o
<
oc
<
® Vocal Fader
The singer’s voice becomes softer than the accompaniment.
(D Auto Vocal Fader
The singer’s voice becomes softer only while there is audio
input through a microphone.
(D Multiplex
The sound on the left channel is heard from both speakers
and the sound on the right channel is muted.
To hear the sound on the right channel, see below.
@ Auto Multiplex
The sound on the left channel is heard from both speakers,
and the sound on the right channel is muted only while there
is audio input through a microphone.
To hear the sound on the right channel, see below.
® Cancel
To change the time lag setting in Auto Vocal Fader or
Auto Multiplex function
The muted original singer’s voice can be turned faster to the
normal level.
When Auto Vocal Fader or Auto Multiplex is selected, “A-VF” or
“A-MPX” is displayed for 3 seconds and changes to the selected
function name. After the selected function name is displayed,
keep pressing KARAOKE until “FAST” is displayed.
To return to the initial setting, select SLOW.
When the power is turned off, SLOW is restored.
To change the audible channel in Multiplex function
When Multiplex is selected, “MPX -L” is displayed for 3 seconds
and changes to the selected function name. After the selected
function name is displayed, keep pressing KARAOKE until “MPX-
R” is displayed.
To return to the initial setting, select MPX-L.
When the power is turned off, MPX-L is restored.
ENGLISH
1 6
