11 . Standard Serial Data Output (SER.OUT)
The standard serial data output can be used to output the data to an A&D printer and a
display unit.
Set the - SG ~ f -3^^ of the F-Functions to use this output.
When using a non-buffered printer like the AD-8117, AD-8117A and AD-8121 etc, the
printer can not receive data while printing. Therfore, set to Я -.35 / for the manual print
mode or auto print mode.
Pin No. Signal
Spin
Current loop
5 pin
Other pins Not used
Case Shield
Related Functions
F-Function Description
Output Data
F~JÜÜ Displayed data
f-30 1 Gross data
f~ 3B г Net data
F-3Ü3 Tare value
F-3Ü Ч Gross data / Net data / Tare value
Output mode F-Function Description
Stream mode F-310 Description of “Stream Mode“ at page 31
Auto print mode F-30 1 Description of “Auto Print Mode“ at page 31
Manual print mode F-30P When pressing the PRINT key each time, the data is output once.
Auto-print condition F-Function Description
Positive data only F-зго
“Inhibition region of output" ^ +5d.
+5D < “permission region of output".
Positive and
negative data
F-зг 1
-5d ^ “inhibition region of output" ^ +6d.
"Permission region of output” < -5d, -i-Sd < “permission region of output”.
F-Function Description
Delay for continual
data
F-33 0 Not used
r 3 3 1 Approximately 2 seconds
Baud rate F-34 600 bps, 1200 bps, 2400 bps
CF-Function Description
[F-Ü1 Data output of tare
[F-ÜB Output on over load and unstable state. Use or not used
[F~03 Format of Header Selection of TR, PT, GS, NT, T, G and N
[F~ 10 Figure number of unit, decimal point Two figures or three figures, dot or comma
