5.2.4.
Minimum Division (Weighing Interval)
Step 4
Step 5
Check the |
d-xx
I
display. The xx is minimum division (01,02, 05,10, 20,50).
Minimum division
Select a minimum division using the following keys,
key... The key to select a parameter,
key... The key to store a parameter and
proceed to step 6.
A
mode
! key..The key not to change a parameter
and proceed to step 6.
M-H key ..... The key to proceed to "5.6. Gravity
Compensation Function".
To Gravity
Compesation Function
To Maximum Capacity
5.2.5.
Maximum Capacity
>
Step 6 Check the [ ixxxx | display. The xxxx is current
Maximum capacity
capacity. Select a new maximum capacity
using the foliowing keys.
key......... . The key to select a figure.
key...........The key to select a number.
key.......... The key to store a parameter
and proceed to step 7 (of the
zero calibration).
A
I
mod
^ key.......... The key not to change a
To Weighing Range
parameter and proceed to step 7
Punction
(of the zero calibration).
To Zero Calibration
PHESETTABg key,,..... The key to porceed to "5.3.
Weighing Range Function".
5. Calibration
Page 14
AD-4329 Weighing Indicator
