5.5. Gravity Compensation Function
□ If the scale is used at the caiibraiion location, it is not necessary to perform this function.
□ it may cause a weighing error, if there is a difference of gravity acceleration
between the installed location and calibration location. This function specifies
these gravity accelerations and corrects span error.
Caution □ The decimal point is not displayed in the function. Ex,
313B =
9.798 m/s^
Step 1 Press the ICALl key in normal weighing mode. The
Normai weighing mode
I
C3L in
is displayed for two seconds. Press the 1M+
key to enter the gravity compensation function.
If you want to cancel the current procedure, press
and hold the |NEi/GR0SS| key and press the |CAL| key. Then,
all parameters are not changed and the calibration
mode is finished. Press the lOperate/Standb^ key to turn the
display off after displaying
CRnCEL
Step 2 The parameter
0
1
xxxx is displayed. Enter the
>
gravity acceleration of the calibration location. The
parameter xxxx is the gravity acceleration.
key.......... The key to select a figure.
key...........The key to select a number.
key.......... The key to store the new gravity
acceleration and proceed to step 3.
A
mode
! key......... The key not to change the value and
proceed to step 3.
Step 3 The parameter
OB
xxxx is displayed. Enter the
gravity acceleration of the installed location. The
parameter xxxx Is the gravity acceleration.
>n key............ The key to select a figure.
7T| key............ The key to select a number.
key...........The key to store the new gravity
acceleration and proceed to step 4.
mode
! key......... The key not to change the value and
proceed to step 4.
Step 4 Now [ ¿W xxxx I is displayed. Press the ICAl] key to
store the parameters. The I
End
I is displayed.
Proceed to steps.
Step 5 Press the loperate/Siandby key to turn display off.
AD-4329 Weighing Indicator
Page 23
2 seconds
Calibrated location
Installed location
CAL
[Ri in
d”0P
M4*
6 I 3000
o
ZERO
>
-V|V
TARE
A
0 t 3138
Q
08 3000
ZERO
>
TARE
A
08 3800
Q
0 1
3198
CAL
End
I/O
0PR/ST8
Turn display off
5.5. Gravity CompensaBon Function
