5.3.1,
Setting Division and Range
Consider the foilowing rules to design the weighing range.
Rule 1 Select the division and range of each weighing range so as to fit the following inequality.
The first range < the second range < the third range
The division of next weighing range is automaticaliy set bigger than division of
lower weighing range. And the division can change.
Rule 2 When setting the dual range, the upper limit value of the second range becomes
the maximum capacity.
When setting the triple weighing range, the upper limit value of the third range
becomes the maximum capacity.
Rules Select a resolution smaller than 10000. The resolution is a value divided the
maximum capacity by the minimum division of the first range.
Mark to indicate the weighing range while this setting
w'
mark
First range
Second range
Third range
Net
ON
Gross
OFF
Procedure
Step 1 Press the |CAL| key to enter the calibration mode.
Then
CHL
i n
is displayed for two seconds.
Normal weighing mode
item Is displayed.
CAM key....... Parameters are stored in the indicator and
is displayed. Press the
End
key to turn the display off.
CAL
[ f ! L
i n
(
To Next page. A)
Press and hold the I
neitgross
I key and press the |CAl| key
All parameters are not changed and the
calibration mode is finished. Press the
Qperate/Standbvl key to turn the display off after
displaying I EdnEEl
AD'4329 Weighing indicator
Page 19
5.3. Weighing Range Function
