8.1.2. Display and Operation
Action of Accumulating Data
□ When accumuiating data, the display blinks once.
If storing accumulation data, the M+ mark Is displayed.
Caution □ This function can not accumulate different unit data. Specify a unit before use.
Display of Accumulation Data
□ When setting to if - I / I (Effective accumulation function) and pressing the ¡MODE
key, the I totRL I is displayed and the total data is displayed with the M+ mark
blinking . If the I mope I key is pressed again, the weighing data Is displayed.
The total data can be output. Refer to "Output of Accumulation Data"
if "Ib/kg" of [f-D I 3 Is selected, the display of "ib", "kg" and "total" is exchanged
with the IMOPEI key in order.
Undoing the Accumulation Data
□ The last weighing data can be deduced from the accumulation data unless new
data is accumulated.
and accumulation data. Step 1
Step 2
Press the ¡MOPEj key to display hatRL
Press and hold the g key more than 3 seconds. The display blinks once and the
last accumulation data before accumlating last weighing data is displayed.
Caution □ External input can not be used.
Clearing the Accumulation Data
Step 1 Press the I mode I key to display I totBl | and accumulation data.
Step 2 Press and hold the |ZERO| key more than 3 seconds. The display blinks once and
the accumuiation data is cleared.
Caution □ External input can not be used.
Output of Accumulation Data
□ Accumulation data can be output to the standard serial output and RS-232C
interface using the manual print mode.
Step 1 Press the | mode | key to display I frolrfff. I and accumulation data.
Step 2 Pressing the IPRIMH key, the count and total of accumulation data are output in order.
] ySpace(20h) Example: Count f 4
. ojo 0 0 0|0I
\ .............. ^
Header Data Terminator
Total fTToiTiA|L|,kl0|0|0|0i0|0|likig|CR[h.|
Header Data Unit Terminator
