support.dell.com Options and Upgrades 2-11
Figure 2-9. Removing a Memory Module
7. Install the new memory module(s) as shown in Figure 2-10:
a. Align the notch in the edge connector with the slot in the center of the
memory module socket.
b. Press the memory module’s edge connector firmly into the socket.
c. Pivot the module down until it clicks.
Figure 2-10. Installing a Memory Module
8. Replace the memory module cover.
9. Reinstall any batteries you removed in step 3.
10. Reconnect your computer and peripherals to electrical outlets.
11. Turn on the peripherals and then turn on the computer.
As the computer boots, it detects the additional memory and automatically
updates the system configuration information.
bottom of computer
memory
module
slot 2
slot 1
bottom of computer
memory
module
slot 2
slot 1
