Gear Case
ITEM
N0. DESCRIPTION
ITEM
N0. DESCRIPTION
1 Groove Pin 3/16 X 1-1/4 18 Impeller Shaft and Worm Gear Set
2 Flanged Bushing 3/4 X 1” X 3/4 19 Carriage Bolt 1/4-20 X 1-1/4
3 0-Ring 3/4 I.D. 20 Seal 3/4 I.D.
4 Roll Pin 1/4 X 1-1/4 21 Washer .805/.842 X 1.469 X .134
5 Bearing Flange 22 Flange Whiziock Nut 1/4-20
6 Radial Bearing 3/4 ID X 1-3/4 OD 23 Flanged Bushing 1/2 X 3/4 X 3/4
7 Center Lock Nut 1/4-20 24 Taptite 3/8-16 X 1/2
8 Rib Neck Bolt 5/16-18 X 3/4 25 Carriage Bolt 1/4-20 X 7/8
9 Set Screw 5/16-18 X 3/8 (932015) 26 Taptite #10-24 X 3/4
10 Pulley 1-1/4 X 7 27 Washer .750/.760 X 1.400 X .062
11 Flange Whiziock Nut 5/16-18 28 Woodruff Key 3/16 X 5/8 X 1/4
12 Hub 29 Gasket
13 Woodruff Key 3/16 X 7/8 X 3/8 30 R.H. Gear Case Half
14 Bearing Flange 31 Auger Shaft
15 Impeller 32 Gear Case Assembly
16 Thrust Collar 33 8 Cz. Tube Ariens Liquid Grease
17 L.H. Gear Case Half 34 Grease Fill
t
7.1 Introduction
WARNING: Remove wire from spark plug
before attempting any repair or adjust­
ment procedures.
When unit is tipped onto housing, remove
enough fuel so that no spillage will occur,
block securely and remove bottom cover.
A
WARNING: Gasoline is highly flammable
and its vapors are explosive. Handle with
care.
Remove Auger/Impeller and gearcase from
housing
according to instructions in
Auger/Impeller Section to perform the follow­
ing procedures.
7.2 Gear Case
Remove six (6) bolts holding right and left gear-
case halves together and remove halves from
rake shaft.
Remove seals from outsides of gearcase
halves with screwdriver, and remove bushings
from outside in with bearing driver.
Remove impeller shaft from gearcase and slide
front flanged bushing off front of impeller
shaft.
Slide 0-Ring and rear flanged bushing off rear
of impeller shaft.
Drive groove pin out of thrust collar and
remove thrust collar from rear of impeller shaft
(drive pin in direction of least resistance).
Remove washers located on each side of
bronze gear. Slide bronze gear off rake shaft
and remove woodruff key from rake shaft.
Inspect all parts and replace if necessary.
Place all parts back on impeller shaft and rake
shaft in reverse order.
Insert assembled rake shaft into left gearcase
half and fill gearcase with 2 oz. of Ariens Liquid
Grease, Part No. 000072.
Insert assembled impeller shaft into left gear-
case half, making sure flanged bushings are
seated correctly.
Replace gearcase gasket and slide right gear-
case half onto rake shaft. Turn input shaft
clockwise until gearcase halves fit snugly
together. Secure with six (6) bolts.
When properly assembled, input shaft should
turn freely.
