Ariens 932 Series - Manual (Page 30)

Friction Wheel Drive
ITEM
NO. OESCRIPTION
ITEM
NO. DESCRIPTION
1 Compression Spring 22 Cap Screw, 5/16-18 x 3/4
2 Shifting Fork 23 Traction Clutch Assembly
3 Flanged Bushing 24 Hairpin, 3/32 X 1-3/16
4 Washer, 1/2 25 Clutch Fork
5 Cap Screw, 5/16-18 x 1-1/2 26 Set Screw, 5/16-18 x 3/8
6 Washer, 5/16 27 Rod Adapter
7 Lock Nut, #10-24 28 Lock Nut, 5/16-18
8 Bushing Flange 29 Bracket
9 Bearing Flange 30 Cotter Pin, 1/8 X 1”
10 Washer, 1/2 31 Cap
11 Lock Nut, 1/4-20 32 Spacer
12 Friction Wheel Hub 33 Extension Spring
13 Friction Wheel 34 Woodruff Key, 3/16 x 3/4
14 Cap Screw, 1/4-20 X 1/2 35 Washer, 5/8
15 Roll Pin, 1/8 X 7/8 36 Flange Bushing, Long
16 Pinion - 37 Drive Plate
17 Carriage Bolt, #10-24 x 3/8 38 Hex Shaft
18 Snap Ring, External 39 Lock Nut, 3/8-16
19 Cap Screw, 1/4-20 x 1-3/4 40 Flange Bushing
20 Clevis Pin 41 Hex Shaft
21 Cotter Pin, 3/32 X 3/4 42 Spacer
