Handlebars and Clutch Controls
»
ITEM
NO.
DESCRIPTION
ITEM
NO.
DESCRIPTION
1
Clutch Spring
24
Washer, 3/8
2
Chain and Connector
25
Lower Handlebar
3
Cap Screw, 1/4-20 X 1/2
26
Carriage Bolt, 5/8-16 X 1/2
4
Attachment Clutch Lever
27
Handlebar Panel
5
Lock Nut, 1/4-20
28
Clamp
6
Tapping Screw, #12-14 X 1-1/2
29
Shorting Wire
7
Pin
30
Taptite, 1/4-20 X 3/8
8
Push Nut
31
Tapping Screw, #8-15 X 3/8
9
Handle Pivot
32
Remote Stop Terminal
10
Nut, 5/8-32
33
Traction Clutch Rod
11
Key Set
34
Washer, 5/16
12
Lock Washer, 5/8
35
Lock Washer, 5/16
13
Key Switch Assembly
36
Cap Screw, 5/16-18 X 3/4
14
Grip
37
Cap Screw, 5/16-18 X 1-1/2
15
Handlebar
38
Bail
16
Flange Whiziock Nut, 5/16-18
39
Machine Screw, 10-24 x 1-1/2
17
Carriage Bolt, 5/16-18 X 1-1/2
40
Tie
18
Cable
41
Curved Head Boit
19
Cover
42
Washer, .312/.343 x .625 x .062
20
Traction Clutch Lever
43
Washer, .370/.390 x .875 x .083
21
Hook Rod
44
Extension Spring, 5-1/4
22
Adjustment Strap
45
Control Box
23
Flange Whiziock Screw, 5/16-18 X 5/8
46
Knob
47
Quadrant Doubler
»
2-5
