Belt Drive
I
ITiM
NO.
DESCRIPTiON
ITEM
NO.
DESCRIPTION
H
Belt Cover
21
Clutch Lever
2
Taptite, 1/4-20 X 3/8
22
Lock Nut, 5/16-18
3
Belt Finger
23
Hub
4
Washer, 5/16
24
Pulley
5
Lock Washer, 5/16
25
Flange Whiziock Nut, 5/16-18
6
Cap Screw, 5/16-24 X 3/4
26
Extension Spring
7
V-Belt (Attachment Drive)
27
Cap Screw, 5/16-18 X 5/8
8
Straight Key, 3/16 X 3/16 X 1”
28
Washer, 5/16
9
Engine Pulley
29
Spacer Bushing
10
Set Screw, 5/16-18 X 3/8
30
Lock Nut, 5/16-18
11
Woodruff Key, 1/8 X 5/8
31
Washer, 5/16
12
Camshaft Pulley
32
Idler
13
V-Belt (Traction Drive)
33
Shoulder Spacer
14
Lock Washer, 5/16
34
Idler Arm
15
Extension Spring
35
Carriage Bolt, 5/16-18 X 1-1/4
16
Roll Pin; 5/32 X 7/8
36
Oval Rivet
17
Washer, 1/2
37
Brake Lining
18
Flanged Bushing
38
Brake Clutch Arm W/Lining
19
Cover
39
Torsion Spring
20
Lever
40
Engine
I
V
4-3
