Auger/lmpeller - Discharge Chute
I
ITEM
KO.
DESCRIPTION
ITEM
NO.
DESCRIPTION
1
Taptite, 1/4-20 X 3/8
31
Cap
1
Gear Cover
32
Carriage Bolt, 1/4-20 X 1-1/4
3
Push Nut
33
Chute Control Crank
4
Taptite, 1/4-20 X 3/8
34
Roll Pin, 1/8 X 3/4
5
Gear Bracket
35
Worm Gear
6
Washer or Bushing
36
Carriage Bolt, 1/4-20 X 1-1/4
7
Hair Pin
37
Worm Clevis
8
Chute Pinion Gear
38
Lock Washer, 5/16
9
Cap Screw, 1/4-20 X 1-1/2
39
Lock Washer 3/8
10
Lock Washer, 1/4
40
Nut, 5/16-18
11
Washer, .312/.343 X .875 X .062
42
Carriage Bolt, 1/4-20 X 5/8
12
Cap Screw, 5/16-18 X 5/8
43
Chute Control Strap
13
Chute Strap
44
Flange Whiziock Nut, 1/4-20
14
Spacer
45
Washer, 1/4
15
Washer, .312/.343 X .875 X .062
46
Hex Nut, 1/4-20
16
Lock Washer, 5/16 ID
47
Lock Nut, 3/8-16
17
Cap Screw, 5/16-24 X 3/4
48
Washer, 3/8
18
Lock Nut, 5/16-18
49
Compression Spring
19
Washer, 5/16
50
Friction Plate
20
Wave Washer
51
Friction Washer
21
Plastic Washer
52
Gear Strap
22
Deflector
53
Chute Gear
23
Carriage Bolt, 5/16-18 X 3/4
54
Carriage Bolt, 3/8-16 X 2-1/4
24
Cap Screw, 5/16-18 X 1/2
55
Washer, 1/4
25
Discharge Chute
56
Lock Washer, 1/4
26
Tapping Screw, 8-32 X 3/8
57
Nut, 1/4-20
27
Machine Screw, 1/4-20 X 3/4
58
Chute Handle
28
Lock Nut, 1/4-20
59
Carriage Bolt, 3/8-16 X 2
29
Chute Control Bracket
60
Lock Washer, 5/16
30 ,
Grip
61
Lock Nut, 5/16-18
