Accessing Local Management
Local Management Supplement
1-3
\
Figure 1-1
802.1D Switching Mode, LM Screen Hierarchy
Device
Menu
Password
Device Configuration Menu
General Configuration
Port Configuration
Menu
Switch Configuration
Network Tools
802.1 Configuration Menu
Device
Statistics
Menu
Switch Statistics
Interface Statistics
RMON Statistics
System Resources Information
Flash Download Configuration
SNMP Community Names Configuration
SNMP Traps Configuration
** Repeater Statistics
29712_43
Broadcast
Suppression
Configuration
Ethernet Full
Duplex Configuration
High Speed
Interface
Configuration
Fast
Ethernet
Interfaces
HSIM
* SmartTrunk
Configuration
Port Redirect Configuration/
Redirect Configuration Menu
Port Redirect
Configuration
VLAN Redirect
Configuration
Notes:
* Refer to the
SmartTrunk User's Guide for the screen hierarchy.
** This screen is only available on repeater devices (2E43-51, 2E43-51R,
2H23-50R, and 2H33-37R).
Indicates the part of the hierarchy that changed.
Repeater Port
Configuration
Module Level
Security Configuration
Port Level
Security Configuration
2H23-50R or
2H33-37R only
Repeater Level
Security Configuration
Port Level
Security Configuration
2E43-51 or
2E43-51R only
** Repeater
Configuration Menu
