GMRP Configuration Screen
Local Management Supplement 4-7
3. Press ENTER.
4. Use the arrow keys to highlight the SAVE command at the bottom of
the screen.
5. Press ENTER. The message “SAVED OK” displays.
4.4 GMRP CONFIGURATION SCREEN
The GMRP Configuration screen, Figure 4-3 , is used to set the GMRP
operation mode of each port.
To access the GMRP Configuration screen, use the arrow keys to
highlight the GMRP GROUP REGISTRATIONS menu item on the
802.1 Configuration Menu screen and press ENTER. The GMRP
Configuration screen displays.
Figure 4-3 GMRP Configuration Screen
The following describes the screen fields.
Port # (Read-Only)
Displays the number of the front panel interface.
2762-34
RETURN EXIT
Port #
1
2
3
4
5
6
7
8
9
10
11
12
Mode
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
Set All Ports: [Forward All Groups]
SAVE
Port #
13
14
15
16
17
18
19
20
21
22
23
24
Mode
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
[Use GMRP Filter Unreg]
NEXT
