Repeater Port Configuration Screen
Local Management Supplement 3-3
Figure 3-2 Repeater Port Configuration Screen
The following are definitions for each field of the Repeater Port
Configuration screen:
PORT # (Read-only)
Indicates the repeater port on the connector selected in the CONNECTOR
field. Refer to
Table 3-1 for the connector (CONN) /repeater port
relationship on the device.
Table 3-1 CONN/Repeater Port Relationship
2H23-50R 2H33-37R
CONN 1 = Repeater ports 1 – 12 CONN 1 = Repeater ports 1 – 12
CONN 2 = Repeater ports 13 – 24 CONN 2 = Repeater ports 13 – 24
CONN 3 = Repeater ports 25 – 36 CONN 3 = Repeater ports 25 – 36
CONN 4 = Repeater ports 37 – 48
PORT# NETWORK# LINK STAT. CURRENT OPER. MODE DESIRED OPER. MODE PORT STAT .
1 1 No Link Unknown [Auto-Neg] [Disabled]
2 2 No Link Unknown [Auto-Neg] [Enabled]
3 1 Link 10Base-T [Auto-Neg] [Enabled]
4 2 No Link Unknown [Auto-Neg] [Enabled]
5 2 No Link Unknown [Auto-Neg] [Enabled]
6 2 No Link Unknown [Auto-Neg] [Enabled]
7 2 No Link Unknown [Auto-Neg] [Enabled]
8 2 No Link Unknown [Auto-Neg] [Enabled]
9 2 No Link Unknown [Auto-Neg] [Enabled]
10 2 No Link Unknown [Auto-Neg] [Enabled]
11 2 No Link Unknown [Auto-Neg] [Enabled]
12 2 No Link Unknown [Auto-Neg] [Enabled]
SAVE SET ALL PORTS: [Auto-Neg] CONNECTOR #: [1] EXIT RETURN
