Chapter 1: Changes to Local Management Screens
1-28 Local Management Supplement
To access the Port Redirect Configuration screen from the Redirect
Configuration Menu screen, use the arrow keys to highlight the PORT
REDIRECT CONFIGURATION menu item and press ENTER. The
Port Redirect Configuration
screen displays.
Figure 1-12 Port Redirect Configuration Screen
The following definitions briefly explain each field of the Port Redirect
Configuration screen:
Source Port (Read-Only)
Shows which ports are currently set as source ports.
Destination Port (Read-Only)
Shows which ports are currently set as destination ports.
NOTE
Only one destination port may be assigned to a source port.
2971-22
Source Port
1
3
6
--
--
--
--
--
Destination Port
2
4
9
--
--
--
--
--
Redirect Errors
ON
ON
OFF
--
--
--
--
--
-------------------- ---------------------- ---------------------
Frame Format
NORMAL
TAGGED
UNTAGGED
--
--
--
--
--
---------------------
Redirect Errors [OFF]
SAVE PREVIOUS
RETURN
RETURN NEXT
Source Port [1]
Destination Port [1]
Status [ADD]
EXIT
Frame Format [UNTAGGED]
