Advanced Port Priority Configuration Screen
Local Management Supplement 1-55
Figure 1-22 Advanced Port Priority Configuration Screen
The following describes each field of the Advanced Port Priority
Configuration screen:
Priority (Read-Only)
Lists the eight priorities, 0 through 7.
TX Queue (Toggle)
Enables the frames with a certain priority to be mapped to transmit
according to one of two TX queues (0 or 1) with 0 being the lowest
transmit level. Refer to
Table 1-2 for the TX Queue default values
according to frame priority.
To set the TX Mapping Queues, refer to Section 1.22.1 .
RX Priority (Read-Only)
Lists the eight priorities, 0 through 7.
Table 1-2 TX Queue Mapping Default Values
Priority 0 1 2 3 4 5 6 7
TX Queue 0 0 0 0 1 1 1 1
2971_88
RETURN SAVE PREVIOUS EXIT NEXT
Priority
0
1
2
3
4
5
6
7
TX Queue
[0]
[0]
[0]
[0]
[1]
[1]
[1]
[1]
TX Priority
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
Port #: xxx Default Priority [7]
Priority/Queue Mapping
-------------------------------
RX Priority
0
1
2
3
4
5
6
7
Priority Regeneration
----------------------------
