Chapter 2: LM Security Screens for 2E43-51/2E43-51R Devices
2-6 Local Management Supplement
Figure 2-3 Port Level Security Configuration Screen
The following section defines the fields on the Port Level Security
Configuration screen.
Port (Read-only)
Lists the repeater ports on the ENET interface connector (ENET 1
through 4) selected in the INTERFACE # field. Refer to
Table 2-1 for the
ENET/repeater port relationship on the device.
Table 2-1 ENET/Repeater Port Relationship
Security State (Selectable)
Used to select the security state of each repeater port on the connector for
frames received. The states are as follows:
• NonSecure – Allows the ports on the connector to receive all frames.
The source address of received frames is not examined and the frames
are processed in a non secure state.
The last source address detected is displayed in the address column.
This provides a quick and easy way to see what address belongs to
what port.
ENET 1 = Repeater ports 1 – 12 ENET 3 = Repeater ports 25 – 36
ENET 2 = Repeater ports 13 – 24 ENET 4 = Repeater ports 37 – 48
Port Security State Action On Intruder Address
1 [LockedOnAddr] [NoD isablePort] [SendTrap] [xx-xx-xx-xx-xx-xx]
2 [NonSecure] [00-00-00-00-00-00]
3 [LockedOnAddr] [DisablePort] [SendTrap] [xx-xx-xx-xx-xx-xx]
4 [LockOnNext] [DisablePort] [SendTrap]
5 [NonSecure] [00-00-00-00-00-00]
6 [NonSecure] [00-00-00-00-00-00]
7 [NonSecure] [00-00-00-00-00-00]
8 [NonSecure] [00-00-00-00-00-00]
9 [NonSecure] [00-00-00-00-00-00]
10 [NonSecure] [00-00-00-00-00-00]
11 [NonSecure] [00-00-00-00-00-00]
12 [NonSecure] [00-00-00-00-00-00]
SAVE INTERFACE #: [1] EXIT RETURN
