Ethernet Full Duplex Configuration Screen

Local Management Supplement

1-17

Figure 1-8

Ethernet Full Duplex Configuration Screen

This section explains each field of the Ethernet Full Duplex Configuration
screen.

PORT # (Read-only)

Identifies the number of the port.

OPERATION MODE (Toggle)

Allows the user to set the specified port to transmit and receive data
separately (Standard) or simultaneously (Full Duplex). Set this field to
one of the following values:

•

STANDARD ENET – The port is running in half duplex (default) and
either transmits data or receives data, but not both at the same time. To
set Ethernet ports for Standard operation, refer to

Section 1.7.1

•

FULL DUPLEX – Depending on the SmartSwitch, the port transmits
and receives data simultaneously at 10 or 100 Mbps, thus enabling the
port to effectively switch at 20 or 200 Mbps. To set Ethernet ports for
Full Duplex operation, refer to

Section 1.7.1

19601-21

PORT #

LINK STATUS

Link

No Link

Link

SAVE

OPERATION MODE

[STANDARD ENET]

PORT STATUS

ENABLED

SET ALL PORTS: FULL

RETURN

[13-24]

EXIT
