Chapter 4: Generic Attribute Registration Protocol (GARP)
4-4 Local Management Supplement
4.3 GARP OPERATION STATUS SCREEN
The GARP Operation Status screen, Figure 4-2 , is used to enable ports on
the switch as GMRP- and GVRP-aware ports. The ports may be enabled
one by one or all at the same time for GMRP and GVRP.
To access the GARP Operation Status screen, use the arrow keys to
highlight the GARP OPERATION STATUS menu item on the 802.1
Configuration Menu screen and press ENTER. The GARP Operation
Status
screen displays.
Figure 4-2 GARP Operation Status Screen
The following describes the screen fields.
Port # (Read-Only)
Displays the number of the front panel interface.
GMRP (Toggle)
Sets the port to operate as a GMRP-aware port. The setting is only valid if
the GMRP Protocol field near the bottom of the screen is set to Enable.
The GMRP field setting toggles between Y (yes) and N (no).
The default is “Y”.
To set the port, refer to Section 4.3.1 .
27621-33
RETURN EXIT
Port #
1
3
5
7
9
11
13
15
17
19
Set All Ports: [GMRP Enable All]
SAVE
Port #
2
4
6
8
10
12
14
16
18
20
NEXT
GMRP
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
GMRP
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
GVRP
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
GVRP
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
[ y ]
GMRP Protocol: [ Enable ] GVRP Protocol: [ Enable ]
PREVIOUS
