PARTS LIST FOR CRAFTSMAN 10 INCH TABLE SAW
MODEL NO. 113.298141,113.298031 & 113.298151
Always order by Part Number — not by Key Number.
FIGURE 1 PARTS LIST
Key
No. Part
No. Description
Key
No.
Part
No. Description
1 62579 Guard Assembly (See Fig. 5) 25 STD 511107 ’Screw, Pan ht
2 STD 522506 *Screw, Hex Hd. 1/4-20 x 5/8 26 STD 551210 ’Lockwasher, External No. 10
3 STD 551225 *Lockwasher, External 1/4 27 62689 Handwheel Assembly
4 STD 541025 * Nut, Hex 1/4-20 28 STD 511103 ’Screw, Pan Hd. 10-32 x 3/8
5 STD 523110 *Screw, Hex 5/16-18x1 29 60354 Nut, Speed No. 8
6 62541 Bar, Fence Rear 30 62701 Panel, Front
7 STD 651231 *Lockwasher, External 5/16 31 STD 610805 ’Screw, Pan Hd, Ty "AS" No. 8x1/2
8 STD 541031 *Nut, Hex 5/16-18 32 62702 Scale, Adjustable Bevel
9 60388 Nut, Self-threading 33 62700 Base
10 62703 Insert Assembly, (Includes Key No. 11 & 12) 34 60252 Guard, Belt
11 62718 Clip, Retaining 35 60255 Clip, "S"
12 STD 501102 *Screw, Locking Set 10-32 x 3/16 36 STD 601105 ’Screw, Pan Hd. Ty "T" 10-32 x 1/2
13 133645 Screw, Fiat Hd. 10-32 x 1 37 60253 Support, Belt Guard
14 62748 Rod, Separation (Includes Key No. 9) 38 60254 Bracket, Support
15 62493 Insert, Exact-I-Cut 39 454896 ’Screw, Hex Hd. 3/8-16 x 1/2
16 62705 Fence Assembly, Rip (See Fig. 3) 40 STD 551237 ’Lockwasher, External 3/8
17 62710 Tape, Fence 41 71165 Tie, Wire
18 62709 Bar Assembly, Fence Guide 42 STD 541411 Nut, Lock 10-32
(Includes Key No. 17) 43 62618 -HVIotor (Model 113.298031)
19 STD 523107 *Screw, Hex Hd. 5/16-18 x 3/4 43 62680 +Motor (Model 113.298151)
20 STD 551031 *Washer, 21/64x5/8 X 1/16 62750 Bag of Loose Parts (Not Illustrated)
21 62539 Spacer, Fence Guide Bar (Includes Bag 62751)
22 60381 Switch Assembly, Box (See Fig. 6) ' 62751 Bag of Loose Parts (Not Illustrated)
23 STD 523117 ’Screw, Hex, 5/16-18 x 1-3/4 62753 Owners Manual (Not Illustrated)
24 62704 Gauge Assembly, Miter (See Fig. 4)
- ' '
* Standard Hardware Item — May Be Purchased Locally.
NOTE: Shipping and handling charges for standard hardware items
{identified by *) such as nuts, screws, washers, etc., make
buying these items by mail uneconomical. To avoid shipping
and handling charges, you may obtain most of these locally.
+ Stock Item — May be secured through the hardware department of
most Sears Retail Stores or Catalog Order Houses,
